順芯半導體_ADC產品清單
| Channel | Package | Master | Master ClockNote1 | SNR(dB) | THD+N(dB) | Head Phone Amp | Speaker | Line | PLL | Special Funcation | Supply Voltage(V) | |
| ES7201 | 2-ch ADC | 2.5x2.5 QFN-12 | Slave | S/USB/NS | 91 | -85 | PDM ADC | 1.7 to 3.6 | ||||
| ES7202 | 2-ch ADC | 3x3 QFN-16 | Slave | S/USB/NS | 95 | -88 | PDM ADC | 1.7 to 3.6 | ||||
| ES7210 | 4-ch ADC | 4x4 QFN-32 | Both | S/USB/NS | 102 | -85 | Up to 16-ch TDM/I2S | 1.7 to 3.6 | ||||
| ES7240S | 2-ch ADC | TSSOP-16 | Both | S/USB/NS | 100 | -85 | 3 to 3.6 | |||||
| ES7241D | 2-ch ADC | 3x3 QFN-16 | Both | S/USB/NS | 100 | -85 | 3 to 3.6 | |||||
| ES7242 | 2-ch ADC | 4x4 QFN-24 | Both | S/USB/NS | 100 | -85 | 4:1 analog mux | 3 to 3.6 | ||||
| ES7243 | 2-ch ADC | 3x3 QFN-20 | Both | S/USB/NS | 102 | -85 | Up to 16-ch TDM/I2S | 1.7 to 3.6 | ||||
| ES7243E | 2-ch ADC | 3x3 QFN-20 | Both | S/USB/NS | 101 | -90 | Up to 16-ch TDM/I2S | 1.7 to 3.6 | ||||
| ES7243Q | 2-ch ADC | 3x3 QFN-20 | Both | S/USB/NS | 101 | -90 | AEC-Q101 qualified Up to 16-ch TDM/I2S | 1.7 to 3.6 | ||||
| ES8218E | 1-ch ADC | 3x3 QFN-28 | Both | S/USB/NS | 95 | -85 | 1.6 to 3.6 |
